STA-CHARGE™

  • For 12V liftgate/load batteries
  • Input voltage: 8V – 16V
  • Output voltage: 14.4V**
  • Maximum input current: 27A
  • Maximum output current: 23A
  • Automatically adjusts output voltage depending on temperature
  • Environmentally sealed connector
  • Anodized cooling heatsink
  • Visual indicator shows status of charging
  • Phillips patented Lock Out feature: stops charging batteries when brakes are pressed
  • Standard mounting pattern
    • When tied to the BLUE circuit, this ensures all power is available during an ABS event
  • Must be used with a Phillips STA-CHARGE™ harness or available harness adapters (see below)

** Voltage is temperature compensated so that in cold temperature the batteries are charged at a higher voltage.

For more information or to order call 800-432-4512

Products

Part #
Description
60-3600
STA-CHARGE™ battery charger
